Fitment

Fit Ford Cleveland V8 302 351 Gear Reduction Auto

Note

Please Check With Pictures / Numbers / Specs Before Ordering.

Specification

Replace Part Number：AF4250-5055

Starter Style：Mini Denso Style

Starter Finish：Powder Coated Black For Extra Corrosion Protection

High Heat Resistance To Help Eliminate Hot Start Problems

4.44:1 Gear Reduction For Maximum Torque

Starter Rotation：Standard

CNC Machined Adjustable Mounting Block For Maximum Clearance

Power Point In Between Block And Starter, Instead Of Between Starter And Headers As Many Other Brands Do, To Allow For Tight Clearances, And Heat Protection To Wiring

Heavy Duty Bearing Holds Drive Assembly For Long Life And Accurate Pinion Alignment

Maximum Recommended Compression Ratio Is A Huge 14:1

Voltage：12 Volts

Power Rating：1.9 HP / 1.4 KW

Mounting Holes Centre To Centre：133mm

Overall Length：198mm

Overall Height：140mm

Overall Width：93mm

Note

Starter Has A 3/4 In. Offset And Fits Applications With Automatic Transmissions Using A 157 Or 164 Tooth Ring Gear Or Manual Transmissions Using A 157 Tooth Ring Gear (Normally 5-Speeds). This Replaces OEM Starters With A 'Nose' That Extends 2-3/8 In. Past The Mounting Surface.

Mounting Holes Are Not Threaded, Which Most Factory Starters Are Not. But In Some Instances The Factory Starter Motor Mounting Holes Are Threaded, Which Means You Will Need To Purchase Appropriate Nuts/Bolts For Mounting, Which Can Be Purchased From Any Good Fastener/Bolt Store.

Adjustable Mounting Block Allows Fitment To Multiple Configurations Of Oil Pan And Extractors, But Please Use The Above Measurements And Information To Compare To Your Original Starter Motor, To Ensure Correct Fitment For Your Vehicle.

Suitable For Models Fitted With Existing 3/4 Offset Starter.

Suitable For Models Fitted With 3 Speed Auto Transmission.

Package

1 x Starter Motor
