Applications
For Cub Cadet           i1046              20HP     2006
For Cub Cadet           i1050              25HP     2006
For Cub Cadet           LT1045LE     20HP     2005 - 2006
For Cub Cadet           LT1046          23HP     2005 - 2006
For Cub Cadet           SLT1550        25HP     2005 - 2006
For Cub Cadet           SLT1554        27HP     2005 - 2006
For Toro                    G4030            23HP     2007 - 2008
For Toro                    G4035            25HP     2009
For Toro                    G4050            25HP     2008
For Toro                    GT2100         23HP     2006 - 2008
For Toro                    GT2200         25HP     2006 - 2008
For Toro                    GT2300         26HP     2006
For Toro                    LX425           20HP     2007
For Toro                    LX468           22HP     2008 - 2009
For Toro                    LX500           22HP     2006
For Toro                   SL500            23HP     2007
For Toro                   TimeCutterZ4202    20HP     2008 - 2009
For Toro                   TimeCutterZ5020    23HP     2007 - 2009
For Toro                  TimeCutterZ5060    25HP      2008 - 2009
For Toro                  TitanZ4800              23HP      2008 - 2009
For Toro                  TitanZ5200              25HP      2007 - 2009



Replace Part Number

For Kohler:
For 3209801  3209801S  32-098-01  32-098-01S
For 3209803  3209803S  32-098-03  32-098-03S
For 3209804  3209804S  32-098-04  32-098-04S
For 3209815  3209815S  3209808    3209808S

For KOH3209801S

For 5801



Specifications

Voltage : 12

Rotation : CCW

Teeth : 10 Tooth Steel Drive Gear - Counter Clockwise Rotation.

Gear OD : 1.283in / 32.6mm

Mounting hole Centres : 68mm

Mtg Ear 1 Hole : 11mm Unthreaded

Mtg Ear 2 Hole : 8mm Unthreaded

Weight : 6.87 lbs / 3.12 kg



Notice

Professional installation is highly recommended (No Instruction Included)

SKU SM-9801-V2
Brand MAX PEEDING RODS
