Specifications

Voltage 12 V

Amps 70 A

Adjustment Hole (mm)    8x10

Pivot Hole (mm)    10.5

Adjustment to Pivot (mm)    175

Pivot Length (mm)    N/A

Inside Feet To Feet (mm)    80

Pulley (mm)    84

No Of Grooves    2A

Reference Number

LR170-407 ,LR170-412, LR170-412S, LR170407;

LR170-407B, LR170-407E, LR170-407S;

LR170407B, LR170407E, LR170407S, LR170407T;

LR170412, LR170412S, 23100-02N14, 23100-02N15;

2310002N15, 2310002N19, 2310002N23, 2310020N01;

23100-02N19, 23100-02N23, 23100-20N01, 2310002N14;

LR140-424/T,  LR150-428E/S/T, LR150-430C/S/T, LR150-435/S/T, LR150-443/T, LR155-411, LR160-426/E/S/T, LR160-437/T, LR165-428, LR170-407/408/421

LR170412T, LR150428S, LR150430S, LR160426S

BXH1204N

Note

Please Check With Pictures / Numbers / Specs Before Ordering.

Fitment

For Nissan Urvan E24 1987-1997 2.7 Diesel TD27
For Nissan Patrol GU Y61 1998-2003 4.2 Diesel TD42
For Nissan Cabstar F22, H40 1987-1990 2.7 Diesel TD27
For Nissan Navara D22 1997-2001 2.7 Diesel TD27
For Nissan Safari Y60 1987-1997 4.2 Diesel TD42
For Nissan Patrol GQ Y60 1988-1999 4.2 Diesel TD42
For Ford Maverick DA 1988-1994 4.2 Diesel TD42
For Nissan Navara D21 1986-1997 2.7 Diesel TD27

Package

1 x Alternator
